Runtime-port laboratory

Port numbers in configuration are useful, but the listener a process actually opens is the stronger fact. This laboratory puts all port cases side by side.

Run it

cd examples/runtime-ports
kranz

Start one service at a time at first; the names describe the scenario.

Scenarios

Service	What to look for in Details
auto-detected	Listener 18301 appears without a ports field
configured-and-detected	18302 declared · listening appears once
different-runtime-port	Stale declaration 18399 stays distinct from listener 18303
dynamic-http-health	Python chooses a port and readiness follows it
configured-only	18304 remains a declaration; no process listens there
subprocess-listener	A child process listener maps back to its Kranz service
cycling-listener	Port 18307 appears and disappears while the process stays alive
two-dynamic-health-ports	Readiness and liveness select different detected ports
detection-disabled	Listener exists, but explicit opt-out keeps it hidden

Start with automatic discovery

Focus auto-detected, press s, then open Details. Kranz scans listeners owned by the service process group and its children. On macOS it uses lsof; on Linux it uses ss.

Expand the service and run check-http. This is a service action: it fetches the endpoint once and records HTTP 200 separately from the service logs.

Dynamic health target

This service asks Python to bind any free port:

dynamic-http-health:
  command: python3 -u -m http.server 0 --bind 127.0.0.1
  healthcheck:
    readiness:
      type: http
      url: http://127.0.0.1/

Because the URL omits a port, the readiness checker waits for listener discovery and inserts the detected port. This is useful for test servers and tools that allocate ports dynamically.

Project actions

Expand example-tools beneath the service list:

• describe demonstrates inherited directory and environment;
• list-files captures a bounded command result;
• confirm-demo demonstrates confirmation without changing project state.

Cleanup

Press a, then s, and confirm. The example opens only localhost ports in the 18301–18307 range plus dynamically allocated loopback ports.

Full source and expected cases are also documented in examples/runtime-ports/README.md.
