Configuration composition

This catalog combines autonomous native Kranz files, a Procfile, and a supported Process Compose file into one effective project. It is safe to explore: the commands below only load and inspect configuration; they do not start services.

Inspect the mixed workspace

Run from the repository root after building or installing Kranz:

kranz config check -C examples/composition/workspace
kranz config sources -C examples/composition/workspace
kranz config sources -C examples/composition/workspace --by-service

The workspace resolves 12 services. Its native files form the recursive tree; the Procfile and Process Compose sources are terminal leaves. Local defaults, dotenv files, relative directories, overrides, protected values, name qualification, and diamond deduplication remain attributable to their sources.

Press m in the TUI to open the same Config Map and Tab to switch between the source tree and the reverse service-to-source view.

Try each boundary

Scenario	What it demonstrates
workspace	Exact, glob, discovery, recursive native files, mixed-format leaves, local and explicitly qualified dependencies, overrides, protected values, and collisions
graph-depth	A bounded include graph and the include_depth_truncated diagnostic
symlinks	Default symlink refusal and canonical deduplication with --follow-symlinks
virtual-root	A stable project discovered without a conventional root file
negatives/cycle	The complete include-cycle chain
negatives/empty-glob	A glob that matched no configuration
negatives/missing-explicit	A missing exact source
negatives/remote	Rejection of non-local sources
negatives/type-mismatch	An override value with an incompatible type
negatives/forbidden-override	Composition directives rejected inside an override layer
negatives/ambiguous-dependency	A cross-source bare dependency with two equally valid targets

For example:

kranz config check -C examples/composition/graph-depth
kranz config check -C examples/composition/virtual-root
kranz config check -C examples/composition/symlinks --follow-symlinks

The negative scenarios are expected to fail with their named diagnostic. The checked-in catalog is loaded by automated tests, so examples cannot silently drift away from the configuration loader.

In workspace, both repository configs declare api. The checkout worker uses the local short form depends_on: [api], which resolves to checkout/api; root-task lives outside both repositories and uses the qualified depends_on: [checkout/api] form. The separate negatives/ambiguous-dependency scenario shows why a root-level bare api cannot be guessed safely.

See Composing configurations for the full contract and the repository's examples/composition/README.md for additional commands.
